R SERIES 2 to 50 Watts                              DC/DC

HIGH RELIABILITY SINGLE(S) DUAL(D) TRIPLE(T) REGULATED,ISOLATED

33/5

0.25

RA

*R5S.25

$78

$71

1.0

CA

*R5S1

$107

$98

12

0.3

RA

*R12S.3

$78

$71

0.8

CA

*R12S.8

$107

$98

5-48

15

0.25

RA

*R15S.25

$78

$71

0.75

CA

*R15S.75

$93

$85

24

0.2

RA

*R24S.2

$78

$71

0.6

CA

*R24S.6

$107

$98

28

0.1

RA

*R28S.1

$78

$71

0.5

CA

*R28S.5

$107

$98

DUAL

±5

±0.25

RA

*R5D.25

$82

$75

±0.75

CB

*R5D.75

$102

$93

5-48

±12

±0.15

RA

*R12D.15

$88

$80

±0.5

CB

*R12D.5

$107

$98

±15

±0.15

RA

*R15D.15

$88

$80

±0.45

CB

*R15D.45

$107

$98

TRIPLE

5±

0.5/0.1

CB

*R5*T.5.1

$108

$99

5±12

0.5/0.2

CC

*R512T.5.2

$119

$109

5- 48

5±12

2.0/0.5

CD

*R512T2.5

$152

$139

5±15

500/.18

CC

*R515T.5.18

$119

$109

5±15

2.0/.45

CD

*R515T2.45

$152

$139

MODEL NUMBER STRUCTURE FOR VOLTAGE/CURRENT NOT SHOWN ABOVE.

SAMPLE: Input: 24Vdc Output: 3.3V@1.5A

Vdc in

        Series                                             Iout

                Vout                  No.of Outputs

   OUTPUT                      CASE  MODEL        PRICING

       Vout(Vdc)      Iout(A)                            1-9     10-Up

*Insert required  Vout Price increase w/Vout

SPECIFICATIONS

PARAMETER

LIMIT

Vac in:  110 to 137Vac 47-420Hz

Regulation Line:

Load:

0.05%

0.1%

Vout Ripple/Noise:

25mVrms

Vin Tolerance:

±10%

Vin reflected ripple

1% Vin

Isolation Input:

500Vdc

Vout Tolerance:

1%

Efficiency

>75%

Temperature Co-efficient:

0.015%/°C

Operating:

-25° to+71°C

Storage:

-55° to+85°C

ShortCircuit Protection: Auto-Recovery
