M SERIES 10 to 70 Watts          AC/DC

LOW NOISE MODULAR(T) & MULTI-OUTPUT(CT)

      OUTPUT        CASE             MODEL         PRICE

±Vout    ±Iout                                          1-9    10-Up

  (Vdc)    (A)

Price increase w/ >Vout *Insert required Vout

TRIPLE

±0.1/.5

CB/MA

MT*.1-.5

$108

$99

±0.2/1

CC/ MB

MT*.2-1

$118

$108

±12

±0.3/1.5

CD/MC

MT*.3-1.5

$126

$115

±15

±0.3/2

CE/ MC

MT*.3-2

$137

$125

±18

±0.4/2.5

 MD

MT*.4-2.5

$147

$138

±24

±0.4/3

 ME

MT*.4-3

$152

$139

±5

±0.5/3.5

 ME

MT*.5-3.5

$163

$149

±0.6/4

 ME

MT*.6-4

$171

$156

SPECIFICATIONS

PARAMETER

LIMIT

Vac in: 110 to 137 Vac 47-420Hz

Regulation  Line:

Load:

0.05%

0.1%

Ripple /Noise :

0.5mVrms (>24Vout

1.0mVrms (<24Vout)

Isolation Input:

Vin/Vout:

50 Meg Ohms

500Vdc

Voltage Accuracy:

1% Fixed

Temperature

Coefficient:

0.015% /ºC

Operating:

-25 C to 71/ºC

Storage:

-55C to 85/ºC

Short Circuit Protection: Auto-Recovery

QUAD (Q)

Voltage/Current preferences available

within wattage specifications above.

MODEL NO. STRUCTURE FOR VOLTAGE/

CURRENT NOT SHOWN ABOVE

SAMPLE: Output: 5±12@4A.8A@120/220Vac

   Series                                                    Option

                                                       Single Iout

No. of  Outputs                       Dual Iout

                          Dual  Vout
