MODEL NO.
STRUCTURE FOR VOLTAGE/
CURRENT NOT
SHOWN ABOVE.
SAMPLE:
Output 18 V@.6A input: 220vac
SERIES
OPTION
Vout Iout
NO.of OUTPUTS
|
|
OUTPUT CASE MODEL PRICING
Vin
(Vdc) Iout (A) 1-9 10-Up
|
|
SINGLE
|
|
3.3,5
|
3.0
|
CB
|
W3.3S3
|
$106
|
$97
|
|
|
5.0
|
CD
|
W3.3S5
|
$123
|
$112
|
|
12
|
2.0
|
CB
|
W12S2
|
$106
|
$97
|
|
|
2.8
|
CD
|
W12S2.8
|
$123
|
$112
|
|
15
|
1.5
|
CB
|
W15S1.5
|
$106
|
$97
|
|
|
2.0
|
CD
|
W15S2
|
$123
|
$112
|
|
24
|
1.2
|
CB
|
W24S1.2
|
$112
|
$102
|
|
|
1.8
|
CD
|
W24S1.8
|
$128
|
$117
|
|
28
|
0.8
|
CB
|
W28S.8
|
$115
|
$105
|
|
|
1.0
|
CD
|
W28S1
|
$130
|
$119
|
|
48
|
0.6
|
CB
|
W48S.6
|
$118
|
$108
|
|
|
1.1
|
CD
|
W48S1.1
|
$133
|
$121
|
|
DUAL
|
|
±5
|
±1.5
|
CB
|
W5D1.5
|
$115
|
$105
|
|
|
±2.5
|
CD
|
W5D2.5
|
$137
|
$125
|
|
±12
|
±1.3
|
CB
|
W12D1.3
|
$115
|
$105
|
|
|
±1.5
|
CD
|
W15D1.5
|
$137
|
$125
|
|
±15
|
±0.8
|
CB
|
W15D.8
|
$115
|
$105
|
|
|
±1.3
|
CD
|
W15D1.3
|
$137
|
$125
|
|
±24
|
±0.6
|
CB
|
W24D.6
|
$118
|
$108
|
|
|
±0.8
|
CD
|
W24D.8
|
$137
|
$125
|
|
SPECIFICATIONS
|
|
PARAMETER
|
LIMIT
|
|
Vac in: 110 to 137 Vac 47-420Hz
|
|
Regulation
Line:
Load:
|
0.05%
0.01%
|
|
Ripple/Noise:
|
25mVrms
|
|
Vout
Accuracy:
|
1% Fixed
|
|
Isolation
Input:
Vin/Vout:
|
50 Meg Ohms
500Vdc
|
|
Efficiency
|
>75%
|
|
Temp. Co-efficient:
|
0.015%/°C
|
|
Operating:
|
-25° to+71°C
|
|
Storage:
|
-55° to+85°C
|
|
ShortCircuit Protection: Auto-Recovery
|
|
|
