Text Box: H SERIES   50 to 100 WATTS                                AC/DC
LOW PARD LINEAR REGULATED & ISOLATED

   OUTPUT        CASE     MODEL          PRICING

Vout         Iout                                1-9      10-Up

(Vdc)        (A)

SPECIFICATIONS

Parameter

Limit

Vac in: 110 to 137 Vac@ 47-420Hz

Regulation line/load:

0.5%

Vout ripple/noise:

50mVrms

Isolation Input:

Vin/Vout:

50 Meg Ohms

500Vdc

Vout Tolerance:

3%

Efficiency:

>80%

Temperature

Coefficient:



0.015%/ºC

Operating:

-25ºC to 71ºC

Storage:

-55ºC to 85ºC

ShortCircuit Protect:  AutoRecovery

SINGLE

5 9

9

ME

H5S9

$195

$178

12

3

ME

H12S3

$169

$154

12

5

ME

H12S5

$195

$178

15

3

ME

H15S3

$169

$154

15

4

ME

H15S4

$190

$173

24

2

ME

H24S2

$180

$164

24

2.5

ME

H24S2.5

$191

$174

28

2

ME

H28S2

$191

$174

DUAL

±5

±4

ME

H5D4

$195

$178

±12

±2

ME

H12D2

$169

$154

±12

±3

ME

H12D3

$190

$173

±15

±2

ME

H15D2

$169

$154

±15

±2.5

ME

H15D2.5

$190

$173

±24

±1

ME

H24D1

$169

$154

±24

±2

ME

H24D2

$195

$178
